Model | KEST-30 | KEST-50 | KEST-75 | KEST-35 |
Brand | Kamtech | Kamtech | Kamtech | Kamtech |
Capacity (kg) | 300 kg | 500 kg | 750 kg | 350 kg |
Maximum table height (mm) |
880 | 1025 | 1025 | 1300 |
Minimum table height (mm) |
290 | 440 | 420 | 370 |
The dimension of table size (mm) |
815x500x50 | 1010x520x50 | 1000x510x55 | 910x500x53 |
Caster wheel (mm) |
Φ 125×40 | Φ 150×48 | Φ 147×50 | Φ 125×40 |
Overall length (mm) |
1145 | 1305 | 1345 | 1210 |
Height of the handle (mm) |
920 | 970 | 935 | 920 |
Lifting speed with load/without load (mm) |
65/94 | 65/94 | 70/80 | 90/110 |
Lowering speed with load/without load(mm) |
98/74 | 98/74 | 50/35 | 100/90 |
Lifting cycle (fully charged) |
120 | 100 | 100 | 100 |
Batteryx2 (vah) |
12×21 | 12×21 | 12×21 | 12×24 |
Vertical travel h4 (mm) |
590 | 585 | 550 | 930 |
Lifting motor (DC24VKW) |
0.8 | 0.8 | 0.8 | 0.8 |
Charger (built-in)24V4A (hr) |
8.5 | 8.5 | 8.5 | 8.5 |
Approx.lifting speed |
10 | 10 | 10 | 10 |
Net weight (kg) |
115 | 157 | 160 | 142 |
